Absorbing foreign advanced technology is the foundation of producing such type bottle unscramble machine. It is developed and researched according to the requirement of high speed direction and this machine is the leading equipment in domestic market.
Quantity:
Share this:
Model: LP-14, LP-16, LP-18
Brand: KM
Product Description
Absorbing foreign advanced technology is the foundation of producing LP-14 type bottle unscramble machine. It is developed and researched according to the requirement of high speed direction and this machine is the leading equipment in domestic market.
Properties and advantage :
a) The main motor speed reducer applies torque limit mechanism to avoid harming the machine when trouble happens.
b) Twice push rowing bottle mechanism is used to ensure every bottle location has bottle which apparently prompts bottle output efficiency.
c) Bottle handling air conveyor prevents bottles from dropping down when in transportation.
d) Damaged bottles shall be rejected according to the reject mechanism.
e) This machine is equipped with blocking bottle detector. It will stop and alarm when bottle blocks.
f) No-bottle detector will send signal to elevator immediately when the bottle quantity is few and elevator shall supply bottles automatically.
g) Photoelectric switch is installed on the air conveyor to control the unscramble machine.
h) Bottle unscramble machine has oil mouths which make the gear, bearing and cam lubrication conveniently.
i) Main electrical appliance (Inverter, PLC, Photoelectric switch, Relay) is from MITSUBISHI、OMRON、SIMENS and so on
Air system uses TAIWAN AIRTAC.
Model
LP-12
LP-14
LP-16
LP-18
LP-21
LP-24
Working location
12
14
16
18
21
24
Output Capacity
4000BPH 500ML
6000BPH 500ML
8000BPH 500ML
12000BPH 500ML
20000BPH 500ML
24000BPH 500ML
Max.Output capacity
6000BPH
18000BPH
10000BPH
14000BPH
22000BPH
28000BPH
Air supply pressure
0.7Mpa
0.7Mpa
0.7Mpa
0.7Mpa
0.7Mpa
0.7Mpa
Air consumption
1.5M3/min
1.5M3/min
1.5M3/min
2M3/min
2M3/min
2M3/min
Adaptive bottle
Φ50-90mm
H 165-290mm
Φ50-96mm
H 165-310mm
Φ50-90mm
H 165-290mm
Φ50-96mm
H 165-310mm
Φ50-96mm
H 165-310mm
Φ50-90mm
H 165-310mm
Motor Power
1.5kw
1.5kw
1.5kw
3kw
3kw
4kw
Auto empty bottle lifter power
0.75kw
0.75kw
0.75kw
0.75kw
0.75kw
0.75kw
External dimension
Φ1660*2060mm
Φ2200*2340mm
Φ2300*2340mm
Φ2640*2340mm
Φ3020*2650mm
Φ3020*2650mm
Weight
2500kgs
3200kgs
3500kgs
3500kgs
3800kgs
4000kgs
Q:How about the spare parts?
A:We will send one year enough easy broken spare parts together with the machines,shipping together.During the warranty time,we will supply the spare parts with our cost including the delivery fees.
Q:How long time for installation?
A:According your machines order,we will send one or two engineers to your plant,it will take about 10 days to 25 days.
Q:How to install my machines when it arrives?how much the cost?
A:We will send our engineers to your factory to install the machines and train your staff how to operate the machines.Customer pay air tickets go and back,accommodation and USD80/day/person.
Q:When can I get my machine after I paid?
A:Normally production time is around 30-60days,the exactly depend on what kind of machine you order.The shipping time is based on your destination port.
Q:What’s your guarantee or the warranty of the quality if we buy your machines?
A:We offer you high quality machines with 1 year guarantee and supply life-long technical support.
Q:Are you a trading company or a manufacturer?
A:We are an Original Equipment Manufacturer so that we can provide you high quality machines in reasonable price, Welcome to visit us.
