Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine
Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine
Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine
Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine
Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine
Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine
Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine
Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine
Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine
Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine
Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine
Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine

Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine Fruit Juice Tubular Uht High Temperature Beverage Sterilizer Machine

1.Tubular UHT (Full-auto control)
2.Fruit juice
3.Pulp containing ≤ 1mm particles, 28 Brix pH ≤3.8
4.60℃→95-105℃(30S)→60℃
5.6,000 L/h

Quantity:
Share this:
  • Model: BR
  • Brand: KM
  • Code: 8422
  • Product Description

Tubular UHT (Full-auto control)

Application product

Fruit juice

(Pulp containing ≤ 1mm particles, 28 Brix pH ≤3.8 )

Technical & Utility

Temperature

60℃→95-105℃(30S)→60℃

Flow rate

6,000 L/h

Steam pressure

≥ 4.0 bar

Steam consumption

420 kg/h

Pure water flow

6,000 L/h (Clean standby)

Compressed air

≥ 6 bar

Tower water flow

30,000 L/h (≤32℃)

Electric power

10.2 kw
